Selelekela
SAE Hydraulic Pipe Flanges ke likarolo tse phahameng- tsa khokahanyo tse etselitsoeng ts'ireletso e sireletsehileng, e lutlang{{1}e leng bopaki ba phetisetso ea mokelikeli ka har'a litsamaiso tse hlokahalang tsa haeteroliki. Li entsoe ho latela maemo a SAE J518 le ISO 6162, li-flange tsena li netefatsa ts'ebetso e tšepahalang-ka khatello e phahameng ea liindasteri.
Litlhaloso
|
KAROLO NO. |
FLANGE KHOLO |
HOSE BORE |
LIEKETSENG |
|||||
|
DN |
LEKHOTLA |
A |
C |
D |
H |
L |
||
|
87641-08-08 |
1/2" |
12 |
08 |
58.9 |
31.7 |
24 |
24 |
7.75 |
|
87641-08-12 |
1/2" |
20 |
12 |
74.9 |
31.7 |
24 |
27.5 |
7.75 |
|
87641-12-10 |
3/4" |
16 |
10 |
72.5 |
41.3 |
32 |
28.2 |
8.76 |
|
87641-12-12 |
3/4" |
20 |
12 |
79.2 |
41.3 |
32 |
31.8 |
8.76 |
|
87641-16-16 |
1" |
25 |
16 |
90.2 |
47.6 |
38 |
34.7 |
9.53 |
|
87641-20-20 |
1.1/4" |
32 |
20 |
103.8 |
54 |
44 |
41.5 |
10.29 |
|
87641-24-20 |
1.1/2" |
32 |
20 |
105.8 |
63.5 |
51 |
45.1 |
12.57 |
|
87641-24-24 |
1.1/2" |
40 |
24 |
116.2 |
63.5 |
51 |
45.5 |
12.57 |
|
87641-32-24 |
2" |
40 |
24 |
125.4 |
79.4 |
67 |
54.7 |
12.57 |
|
87641-32-32 |
2" |
50 |
32 |
135.7 |
79.4 |
67 |
52.7 |
12.57 |
Lintlha tsa Parameters / Technical
|
Ea mantlha |
Zhejiang, China |
Letsatsi la thomello |
E ka buisanoa |
|
Setifikeiti |
GB/T19001-2016 idt ISO9001:2015 |
Ho paka |
maemo a kantle ho naha |
|
Lintho tse bonahalang |
Tšepe ea Carbon |
Tiisetso |
1 selemo |
|
Nako ea tefo |
TT |
MOQ |
2000 |
|
Boemo |
E ncha |
Mmala |
Zinc e tšoeu, zinki ea 'mala |
Mabapi le Khampani
Melemo
Ts'ebetso ea Khatello e sa Lekaneng
E etselitsoe ho mamella khatello ea ho fihla ho 10,000 PSI
Khatello e phahameng ea 30% ho feta litlhoko tse tloaelehileng tsa SAE
E boloka botšepehi ba tiiso tlas'a maemo a khatello e matla ea libaesekele
Precision Manufacturing Excellence
CNC e entsoe ho ± 0.005" mamello bakeng sa ho lekana hantle
Kaho e entsoeng (e sa lahliloeng) bakeng sa matla a holimo
Likarolo tse nyane-tse phethiloeng tsa ho tiisa (Ra <0.4μm)
Boleng bo Phahameng ba Lintho
Lifofane{{0}litšepe tsa k'habone tse nang le matla a matla a ho thibela mokhathala
Khetho ea 316L ea tšepe e sa hloekang e nang le 5x ho hanyetsa kutu
Tšebeliso e felletseng ea thepa e nang le litifikeiti tsa tlhahlobo ea leloala
Tiisetso ea - ea Leak
Proprietary Quad-Theknoloji ea Seal™ (ea mantlha, ea bobeli, le li-backups tse peli)
Mehele e kentsoeng{{0}ea holimo{1}}ea tšebetso ea FKM O-(-65 degrees F ho isa ho +400℃F)
Khatello ea 100% e lekiloeng ho 1.5x khatello ea ho sebetsa
Indasteri-E Eketsehileng Tšireletseho
50% bophelo bo bolelele ba ts'ebeletso ho feta maemo a indasteri
Libaka tse khethehileng tse thatafalitsoeng bakeng sa lisebelisoa tsa mokelikeli oa abrasive
Kameho-moetso o hananang le maemo a{1}}litikoloho tse phahameng
Tumellano ea Lefatše le Setifikeiti
E netefalitsoe ho SAE J518, ISO 6162, le ASME B16.5
PED 2014/68/EU e tsamaellana
Litumello tsa ABS le DNV{0}GL tsa marine lia fumaneha
Tlhophiso Melemo
Laser{0}}matšoao a boitsebahatso a hlophisitsoeng bakeng sa mokhoa o bonolo
E hlophisitsoe{{0}ka pele le litataiso tsa ho tsamaisana
40% ho kenya ka potlako ho feta li-flange tse tloaelehileng
Bokhoni ba ho Itloaetsa
E fumaneha ka boholo ho tloha ho 1/4" ho isa ho 6"
Lisebelisoa tse khethehileng tse kenyelletsang Monel, Hastelloy, le titanium
Litlhophiso tsa boema-kepe tse ikhethileng le litekanyetso tsa khatello
Tiisetso e Matla ea Boleng
Netefatso ea 100% ka CMM
Tlhahlobo ea Ultrasonic bakeng sa botšepehi ba lintho tse bonahalang
Batch traceability e nang le linomoro tse ikhethang tsa serial
Tšehetso e ke keng ea lekanngoa ea Theknoloji
Sehlopha sa boenjiniere ba kopo e inehetseng
Tlhahlobo ea mahala ea hydraulic system
Ho-thupelo ea ho kenya setšeng e teng
LBH
P: Li-flange tsa hau tsa SAE li latela litekanyetso life?
A: Li-flange tsa rona li kopana:
SAE J518 (Khouto 61 & 62)
ISO 6162 (Letoto la 1 & 2)
DIN 20066
ASME B16.5 (ka kopo)
P: Ke litekanyetso life tsa khatello tse teng?
A: Lihlopha tse tloaelehileng tsa khatello:
3000 PSI (207 bar) letoto le tloaelehileng
6000 PSI (414 bar){2}}letoto la khatello e phahameng
Meetso ea tloaelo ho fihla ho 15,000 PSI (1034 bar)
P: U fana ka lisebelisoa life?
A: Lisebelisoa tse tloaelehileng:
AISI 4130 tšepe ea carbon
304/316 tšepe e sa hloekang
Li-alloys tse khethehileng:
Duplex 2205
Setšoantšo sa 625
Titanium Grade 5
P: Nka khetha boholo bo nepahetseng ba flange joang?
A: Lintlha tsa bohlokoa tsa khetho:
Pipe nominal size (NPS)
Khatello ea ho sebetsa tsamaisong
Litlhoko tsa phallo (GPM)
Boemo ba mocheso
Baenjineri ba rona ba fana ka therisano ea mahala ea boholo
P: Ke likhetho life tsa ho tiisa tse teng?
A: Litlhophiso tsa ho tiisa:
O-ring face seal (ORFS) - e tloaelehileng
RTJ (Lenonyello la Mofuta oa Lesale)
Sefahleho se bataletseng se nang le leqeba la spiral gasket
Tšepe-ho{1}}ho{1}}metal seal bakeng sa-lisebelisoa tsa mocheso o phahameng
P: Na li-flange tsa hau li ka fetoha le mefuta e meng?
A: E, li-flanges tsa rona:
Boloka tumellano e felletseng ea maemo a SAE/ISO
E na le 100% e feto-fetohang le meralo e tloaelehileng
Kenyelletsa libaka tsa ho nyalana tse laoloang- tse laoloang
P: Nako ea hau ea ho etella pele bakeng sa litaelo tsa tloaelo ke efe?
A: Nako ea tlhahiso:
Lintho tsa Stock: Ho romelloa ka lihora tse 24
Tloaelo e tloaelehileng: 5-7 matsatsi a ho sebetsa
Li-alloys tse khethehileng: libeke tse 2-3
Libaka tsa tlhahiso ea maemo a tšohanyetso lia fumaneha
P: Na u fana ka ts'ehetso ea ho kenya?
A: Sephutheloana sa tšehetso se felletseng:
Li-calculator tsa torque tsa dijithale
Litšoantšo tsa ho kenya 3D
Litataiso tsa ho kenya masimong
Ho-romelloa ha litsebi tsa sebaka (ka boikhethelo)
P: U boloka litifikeiti life?
A: Litifikeiti tsa hajoale:
ISO 9001:2015 (QMS)
API Q1 (Oli le Khase)
PED 2014/68/EU Sehlopha sa IV
DNV{{0}GL Marine
P: Ke tlhokomelo efe e khothalletsoang?
A: Tlhokomelo e thibelang:
Netefatso ea torque ea selemo le selemo
Tlhahlobo ea tiiso ea lilemo tse peli
Teko ea ultrasonic ea lilemo tse 5
Phetoho ka mor'a lipotoloho tse 50,000
